| Alimentation |
24 VDC ±10% |
| Méthode de contrôle |
Bipolar PWM drive with 32bit MCU |
| Consommation de courant |
Max 500mA (Except motor current) |
| Température ambiante |
In use : 0 - 50°C / In storage : -20 - 70°C |
| Humidité |
In use : 35 - 85% RH (Non-Condensing) / In storage : 10 -90% RH (Non-Consending) |
| Vib. Resist |
0,5g |
| Vitesse de rotation |
0 - 3,000 (rpm) |
| Résolution (ppr) |
500 1,000 1,600 2,000 3,200 3,600 4,000 5,000 6,400 8,000 10,000 20,000 25,000 36,000 40,000 50,000 (Selectable by parameter) *Default: 10,000 |
| Fonctions de protection |
Over Current Error, Over Speed Error, Step Out Error, Over Temperature Error,Over Regenerated Voltage Error, Motor Connect Error, Motor Voltage Error, System Error, ROM Error |
| 7-Segment |
Power, Alarm, Communication ID |
| IO Signal - Signaux d'entrée |
3 dedicated inputs (LIMIT+, LIMIT-, ORIGIN), 7 programmable inputs (Photocoupler) |
| IO Signal - Signaux de sortie |
1 dedicated output (Compare Out), 1 programmable output (Photocoupler), Brake |
| Retour à l'origine |
Origin Sensor, ±Limit sensor |
| Interface de communication |
RS-485 serial communication
Communication speed: 9,600~921,600[bps] |
